Crawler dynamic compactor
XGH350
ProjectUnitParameterTamping energy levelt.m350/800Max. allowed rammer weightt17.5/40Max. droping dis
Parameters
| Item | Unit | Value |
|---|---|---|
| Tamping energy level | t.m | 350/800 |
| Max. allowed rammer weight | t | 17.5/40 |
| Max. droping distance | m | 20/20 |
| Max. height from pulley center to ground | m | 26/26 |
| The length of the boom | m | 19～25/19～28 |
| working angles | ° | 61～78/57～63 |
| Operating Radius | m | 7～11/12～14.8 |
| grounded length | mm | 5200 |
| Wheelbase | mm | 4000 |
| Track link width | mm | 760 |
| Size of Host Machine | m | 8.0×3.36×3.3 |
| Hoisting rope diameter | mm | 28 |
| Single rope tension | t | 8 |
| Full load lifting speed | m/min | 0～112 |
| Range of rope diameter | mm | 20 |
| radius changing speed | m/min | 57 |
| turning speed | r/min | 2 |
| traveling speed | km/h | 1.2 |
| gradeability | % | 40 |
| Ground pressure | MPa | 0.068 |
| Engine | — | SHANGHAI |
| Model | — | SC9D260G3 |
| engine power | kW | 192 |
| Emission | — | euro3 |
| The basic arm weight | t | 55.5(25m main Boom) |
| counter weight | t | 16 |
| The host weight | t | 33 |
