Rough terrain forklift
CPRT18
CPRT18 — Rough terrain forklift. Professional construction equipment by CANMAX.
Parameters
| Item | Unit | Value |
|---|---|---|
| CPRT18(Diesel) — Rated capacity | kg | 1800 |
| CPRT18(Diesel) — Load centre | mm | 500 |
| CPRT18(Diesel) — Lift height | mm | 3000 |
| CPRT18(Diesel) — Free lift height | mm | 105 |
| CPRT18(Diesel) — Fork sizeL×W×T | mm | 1070x100x35 |
| CPRT18(Diesel) — Fork regulating range Min./Max. | mm | 200-1310 |
| CPRT18(Diesel) — Mast tilt angle F/R | Deg | 10°/12° |
| CPRT18(Diesel) — Front overhang | mm | 509 |
| CPRT18(Diesel) — Rear overhang | mm | 520 |
| CPRT18(Diesel) — Min. ground clearance | mm | 250 |
| CPRT18(Diesel) — Length to face of fork (without fork) | mm | 2910 |
| CPRT18(Diesel) — Overall width | mm | 1440 |
| CPRT18(Diesel) — Mast lowered height | mm | 2148 |
| CPRT18(Diesel) — Mast extended height (with backrest) | mm | 4150 |
| CPRT18(Diesel) — Overhead guard height | mm | 2256.5 |
| CPRT18(Diesel) — Turning radius(outside) | mm | 2840 |
| CPRT18(Diesel) — Min. right angle stacking aisle width (add load length and clearance) | mm | 4760 |
| CPRT18(Diesel) — Travel(Unladen/Laden) | Km/h | 20/18 |
| CPRT18(Diesel) — Lifting(Laden) | mm/s | 590 |
| CPRT18(Diesel) — Lowering(Laden) | mm/s | 450 |
| CPRT18(Diesel) — Max. Drawbar pull(Laden/unladen) | KN | 13 |
| CPRT18(Diesel) — Tread front | mm | 1125 |
| CPRT18(Diesel) — Tread Rear | mm | 1185 |
| CPRT18(Diesel) — Tyre pressure front | bar | 620 |
| CPRT18(Diesel) — Tyre pressure rear | bar | 650 |
| CPRT18(Diesel) — Seat to ceiling inside height | mm | 1025 |
| CPRT18(Diesel) — Wheelbase | mm | 1880 |
| CPRT18(Diesel) — Self weight | kg | 3700 |
| CPRT18(Diesel) — Battery(Voltage/Capacity) | V/Ah | 12/90 |
| CPRT18(Diesel) — Rated output/r.p.m. | kw | 42.1/2300 |
| CPRT18(Diesel) — Rated torque/r.p.m. | N.m | 186-206/1700 |
| CPRT18(Diesel) — Bore×Stroke | mm | 98×110 |
| CPRT18(Diesel) — Displacement | L | 3.318 |
| CPRT18(Diesel) — Fuel tank capacity | L | 55 |
| CPRT18(Diesel) — Operating pressure(For attachments) | Mpa | 16.5 |
| CPRT18(Diesel) — Min. right angle stacking aisle width (add load length and clearance) | mm | 2840 |
CPRT18(Diesel)
| Item | Unit | Value |
|---|---|---|
| Max. Gradeability(Laden) (％) | — | 20 |
| Tyre front | — | 12-16.5-12PR |
| Tyre Rear | — | 27×10-12-12PR |
| Engine Model | — | 4TNE98-BQFLC |
| Engine Manufacture | — | YANMAR |
| No. of cylinder | — | 4 |
| Transmission Manufacture | — | China |
| Type | — | YQXD30-XH |
| Stage F/R | — | one / one |
