Articulated boom aerial working platform
CM5070JGKA
Main Feature ： ● Electro-hydraulic proportional control, stepless throttle ● Control box at both turret and platform ● With a 2-section telescopic boom crane ● Limit switch and alarm ● Large outrigger span, outrigger can be operate individually ● Emergency descent power ● Safety
Parameters
| Item | Unit | Value |
|---|---|---|
| Model | — | XHZ5070JGKA |
| Chassis Model | — | NKR77PLLWCJAY |
| Platform Safe Work Load | — | 200kg |
| Max. Work Height | — | 18.2m |
| Max. Work Range | — | 9.3m |
| Seating Capacity | — | 5 people |
| Dimension | — | 8050×2030×3150mm |
| Crane Max. Lift Weight | — | 2000kg |
| Crane Max. Lift Height | — | 9.8m |
