Articulated boom aerial working platform
CM5063JGKA
● Electro-hydraulic proportional control, stepless throttle ● Control box at both turret and platform ● With a 2-section telescopic boom crane ● Limit switch and alarm ● Large outrigger span, outrigger can be operate individually ● Emergency descent power ● Safety interlock
Parameters
| Item | Unit | Value |
|---|---|---|
| Model | — | XHZ5063JGKA |
| Chassis Model | — | JX1060TSG23 |
| Platform Safe Work Load | — | 200kg |
| Max. Work Height | — | 16.2m/17m |
| Max. Work Range | — | 8.1m |
| Seating Capacity | — | 5 people |
| Dimension | — | 7690×2000×2935mm |
| Crane Max. Lift Weight | — | 990kg /2000kg(optional) |
| Crane Max. Lift Height | — | 9.0m |
