Parameters
Main Technical Parameters
| Item | Unit | Value |
| Working height | — | 62.3 ft |
| Overall operating weight(standard) (53 t (without driling tools)) | — | 58.4 ton (us) |
| Max.drilling diameter (Φ800 mm) | — | 31.5in |
| Max. driling depth | — | 59 ft |
Dimensions
| Item | Unit | Value |
| Working condition | — | 310x165x750 in |
| Transport condition | — | 551x117x136 in |
| Engine (Cummins QSB7-C202) | — | Cummins QSB7-C202 |
| Rated power | — | 201 hp/2050 rpm |
| Emission standard (CN III&EU III) | — | CN III&EU III |
| Fuel tank capacity | — | 103 US gal |
Rotary drive
| Item | Unit | Value |
| Rated output torque | — | 118010 lbf*ft |
| Rotary speed | — | 5-35rpm |
Crowd cylinder
| Item | Unit | Value |
| Max.crowd force push/pull | — | 35970 lbf/35970 lbf |
| Max.stroke | — | 14ft |
Crowd winch (optional)
| Item | Unit | Value |
| Max. crowd force push/pull | — | 35970lbf/40466 lbf |
| Max. stroke | — | 43ft |
Main winch
| Item | Unit | Value |
| Max.pulling force | — | 35970 lbf |
| Max. line speed | — | 262 ft/min |
Auxiliary winch
| Item | Unit | Value |
| Max. puling force | — | 13489 Ibf |
| Max.line speed | — | 262 ft/min |
Mast inclination
| Item | Unit | Value |
| Lateral/forward/backward | — | ±4° /5° /90° |
Undercarriage
| Item | Unit | Value |
| Max. travel speed of overall unit | — | 1.3 mph |
| Min. ground clearance | — | 15 in |
| Width of triple grouser track shoes | — | 27.6 in |
| Width of crawlers retracted/extended | — | 117 -165in |
| Max. climbable gradient of overall unit | — | 35% |
| Ground pressure | — | 12 psi |
Hydraulic system
| Item | Unit | Value |
| Hydraulic oil tank capacity | — | 106 Us gal |
| Working pressure | — | 5076 psi |
