Sweeper truck
XZJ5100TXSQ5
XZJ5100TXSQ5 — Sweeper truck. Professional construction equipment by CANMAX.
Parameters
| Item | Unit | Value |
|---|---|---|
| Vehicle model | — | XZJ5100TXSQ5 |
| Chassis models | — | QL1100A8LAY |
| Engine Model | — | JX493ZG3 |
| Overall dimensions(L*W*H) | mm | 7000×2200×2640 |
| Curb weight | kg | 7250 |
| Operating weight | kg | 10055 |
| Clean sweep width | m | 3.4 |
| Wash the sweep speed | Km/h | 3~20 |
| Cleaning width | m | 3.2 |
| Sweeping Speed | Km/h | 3~20 |
| The cleaning water pressure rating | MPa | 10 |
| Cleaning water rated flow | L/min | 80 |
| The Max cleaning Capacity | ㎡/h | 64000 |
| Working Efficiency ((%)) | — | ≥95 |
| Discharging Angle ((°)) | — | ≥45 |
| Clear water tank capacity | m³ | 6.2 |
| Garbage Tank capacity | m³ | 3.5 |
