Parameters
| Item | Unit | Value |
| working paremeters — Static linear load | N/cm | 385 |
| working paremeters — Vibration frequency | Hz | 28/35 |
| working paremeters — theoretical Vibration | mm | 1.86/0.88 |
| working paremeters — Vibration force | kN | 305/225 |
| working paremeters — Compaction width | mm | 2130 |
| working paremeters — minimum ground clearance | mm | 440 |
| Speed range — I | km/h | 0-4.5 |
| Speed range — II | km/h | 0-6.0 |
| Speed range — III | km/h | 0-7.2 |
| Speed range — IV | km/h | 0-12 |
| Speed range — minimum turning radius | mm | 6415 |
| Speed range — wheel base | mm | 6415 |
| weight parameters — working weight | kg | 14000 |
| weight parameters — Distribution of driving wheel weight | kg | 5800 |
| weight parameters — Vibration wheel distribution weight | kg | 8200 |
| Size parameters — Overall dimensions (L*W*H) | mm | 6200×2340×3200 |
| engine — rated speed | r/min | 2200 |
| engine — rated power | kW | 125 |
| engine — fuel consumption | g/kW·h | 235 |
Speed range
| Item | Unit | Value |
| Theoretical gradeability | — | 40% |
engine
| Item | Unit | Value |
| Model | — | 6BTAA5.9-C |
