Cold milling machine
XM200E
XM200E — Cold milling machine. Professional construction equipment by CANMAX.
Parameters
| Item | Unit | Value |
|---|---|---|
| Max.milling and mixing width | mm | 2000 |
| Max.milling and mixing depth | mm | 320 |
| Drum diameter with tools | m | 162 |
| Milling drum diameter | mm | 980 |
| Engine model | — | DHP13 |
| Enigine Manufacture | — | weichai |
| Engine speed | rpm/min | 2100 |
| Rated power | kw | 390 |
| Fuel tank capacity | L | 1400 |
| Water tank capacity | L | 3400 |
| Travel speed | km/h | 0-34 |
| Operating speed | m/min | 0-5 |
| Gradeability | % | 0.6 |
| Operating weight ((kg)) | — | ≤34000 |
| Ground clearance | mm | 320 |
| Complete dimension(L*W*H) | mm | 7530×2500×3000 |
| Conveyor(L*W*H) | mm | 8000×1150×1500 |
