Asphalt paver
RP600
RP600 — Asphalt paver. Professional construction equipment by CANMAX.
Parameters
| Item | Unit | Value |
|---|---|---|
| Working Parameter — Theoretical Productivity | t/h | 500 |
| Working Parameter — Max. paving width | m | 5.85 |
| Working Parameter — Max. paving thickness | mm | 200 |
| Working Parameter — Max Paving speed | m/min | 20 |
| Working Parameter — Compactedness | % | 85 |
| Travel speed parameters — Maximum travel speed | km/h | 3.3 |
| Travel speed parameters — Gradeability | % | 20 |
| Conveyor&feeding parameter — Scraper conveyor speed | m/min | 0～20 |
| Conveyor&feeding parameter — Screw feeding speed | r/min | 0～90 |
| Conveyor&feeding parameter — Screw diameter | mm | 420×280 |
Working Parameter
| Item | Unit | Value |
|---|---|---|
| Pavement evenness ((mm/3m)) | — | ≤2 |
| Transverse levelling accuracy ((%)) | — | ≤5 |
Travel speed parameters
| Item | Unit | Value |
|---|---|---|
| Drive type | — | crawler type |
Mini diameter of turning circle
| Item | Unit | Value |
|---|---|---|
| Service braking system | — | hydrostatic |
| Parking braking system | — | Multiple brake disk, hydraulic release |
| Track tension ((crawler type )) | — | hydraulic track tension |
Conveyor&feeding parameter
| Item | Unit | Value |
|---|---|---|
| Type | — | independent conveyo&feeding |
| Drive type | — | left /right independent hydraulic drive |
| Lubricating system | — | automatic centralized grease lubrication |
