Truck mounted crane
SQ12SK3Q
ModelSQ12SK3QUnitMax Lifting Capacity12000kgMax Lifting Moment30T.MRecommend Power30kwMax Oil Flow o
Parameters
| Item | Unit | Value |
|---|---|---|
| Max Lifting Capacity | kg | 12000 |
| Max Lifting Moment | T.M | 30 |
| Recommend Power | kw | 30 |
| Max Oil Flow of Hydraulic System | L/min | 63 |
| Max Pressure of Hydraulic System | MPa | 26 |
| Oil Tank Capacity | L | 160 |
| Rotation Angle | — | All Rotation |
| Crane Weight | kg | 4200 |
| Installation Space | mm | 1300 |
| Choice of Chassis | — | DFL1250A9; DFL1311A3 ; CA1240PK2L7T4EA81; EQ5201GFJ6; BJ1317VNPJJ-S5; BJ5253ZKPJJ; DFL1253AX; |
| Working radius | m | 4.8 |
| Lifting capacity | kg | 6000 |
