Parameters
| Item | Unit | Value |
| Dimension — Overall Length | mm | 12650 |
| Dimension — Overall Width | mm | 2500 |
| Dimension — Overall Height | mm | 3380 |
| Weight — Travelling Weight | kg | 29400 |
| Weight — Axle Load | kg | 6200/23200 |
| Travelling — Max.Travelling Speed | km/h | 75 |
| Turning — Min Diameter of Turning Circle | m | 21.5 |
| Turning — Minimum Ground Clearance | mm | 275 |
| Turning — Approach Angle | ° | 16 |
| Turning — Departure Angle | ° | 13 |
| Turning — Fuel Consumption Per Hundred Kilometers | L | 37 |
| Main Performance Parameters — Max.Rated Lifting Capacity | t | 25 |
| Main Performance Parameters — Min.Rated Range | m | 3 |
| Main Performance Parameters — Max. Lifting Moment of Basic Boom | kN·m | 1010 |
| Main Performance Parameters — Turning Radius of Platform Tail | mm | 3065 |
| Outriggers — Lengthways | m | 5.14 |
| Outriggers — Transverse | m | 6 |
| Max. Lifting Height — Basic Boom | m | 10.7 |
| Max. Lifting Height — Full-extend boom | m | 34.19 |
| Max. Lifting Height — Full-extend boom + jib | m | 42.15 |
| Outrigger--horizontal — Open Simultaneously--horizontal | s | 30 |
Kinetic Parameter
| Item | Unit | Value |
| Engine Model | — | SC8DK280Q3/WD615.329 |
| Rated Power ((kw/(r/min))) | — | 206/2200 213/2200 |
| Rated Torque ((N.m/(r/min))) | — | 1112/1400 1160/1400 |
Turning
| Item | Unit | Value |
| Max Gradeability ((％)) | — | 30 |
Lifting Speed
| Item | Unit | Value |
| Main Hoisting Mechanism ((s)) | — | ≥120 |
| Auxiliary Hoisting Mechanism | — | ≥120 |
