Parameters
| Item | Unit | Value |
| Engine (Model) | — | D6114ZLQ5B |
| Overall width (mm) | — | ≤2500 |
| Overall height | mm | 3500 |
| Axle 2, Axle 3 | kg | 19870 |
| Travel performance (Travel speed) | — | Max. travel speed |
| Min. stable travel speed (km/h) | — | ≤4 |
| Min. turning diameter at boom tip (m) | — | ≤22 |
| Min. ground clearance (mm) | — | ≥273 |
| Approach angle ((°)) | — | ≥21 |
| Departure angle ((°)) | — | ≥10 |
| Braking distance (at 30km/h with full load) (m) | — | ≤9.5 |
| Max. grade-ability (％) | — | ≥23 |
| Fuel consumption for 100km | L | 36 |
| Min. rated working radius | m | 3 |
| Turning radius at turntable tail (m) | — | ≤3.56 |
| Fully extended boom | kN.m | 521 |
| Fully extended boom + Jib | kN.m | 280 |
| Lateral | m | 6 |
| Fully extended boom (m) | — | ≥31.5 |
| Fully extended boom + Jib (jib offset 5°) (m) | — | ≥39.2 |
| Fully extended boom + Jib (jib offset 30°) (m) | — | ≥38 |
| Boom full extension time (s) | — | ≤115 |
| Max. swing speed | r/min | 3 |
| Hoist speed (Main winch) | — | Full load |
| Noise limit (Crane exterior noise) | — | dB (A) |
| At seated position (dB (A)) | — | ≤90 |
