Parameters
| Item | Unit | Value |
| Dimension — Overall Length | mm | 18090 |
| Dimension — Overall Width | mm | 3000 |
| Dimension — Overall Height | mm | 4000 |
| Dimension — Wheel Tread | mm | 2590*7 |
| Weight — Travelling Weight | kg | 84000 |
| Weight — Axle Load | kg | 12000*7 |
| Travelling — Max.Travelling Speed | km/h | 76 |
| Travelling — Min.Stable Travelling Speed | km/h | 2 |
| Turning — Min Diameter of Turning Circle | m | 24 |
| Turning — Min Diameter of Turning Circle of Boom Head | m | 32.2 |
| Turning — Minimum Ground Clearance | mm | 280 |
| Turning — Approach Angle | ° | 16 |
| Turning — Departure Angle | ° | 17 |
| Turning — Fuel Consumption Per Hundred Kilometers | L | 105 |
| Main Performance Parameters — Max.Rated Lifting Capacity | t | 450 |
| Main Performance Parameters — Min.Rated Range | m | 3 |
| Main Performance Parameters — Max. Lifting Moment of Basic Boom | kN·m | 13500 |
| Main Performance Parameters — Turning Radius of Platform Tail | mm | 6900 |
| Outriggers — Lengthways | m | 9.6 |
| Outriggers — Transverse | m | 9.6 |
| Max. Lifting Height — Basic Boom | m | 16 |
| Max. Lifting Height — Full-extend boom | m | 80 |
| Max. Lifting Height — Full-extend boom + jib | m | 130 |
| Boom Length — Basic Boom | m | 15.3 |
| Boom Length — Full-extend boom | m | 80 |
| Boom Length — Full-extend boom + jib+ extension section | m | 84 |
| Working Speed — Max Rotating Speed | r/min | 1.2 |
| Lifting Speed — Main Hoisting Mechanism | m/min | 148 |
| Lifting Speed — Winch of Luffing jib | m/min | 40 |
| Boom Extend-retract Time — Full-extend | s | 900 |
| Boom Extend-retract Time — Full-retract | s | 900 |
| Luffing Time — Full Extension Time | s | 90 |
| Luffing Time — Full Retract Time | s | 90 |
| Outrigger--horizontal — Open Simultaneously--horizontal | s | 40 |
| Outrigger--horizontal — Close Simultaneously--horizontal | s | 25 |
| Outrigger--Vertical — Open Simultaneously | s | 70 |
| Outrigger--Vertical — Close Simultaneously | s | 40 |
Engine Model(Upper)
| Item | Unit | Value |
| Engine Model(Chassis) | — | OM502LA.E3B/2 |
| Rated Power ((kw/(r/min))) | — | 442/1800 |
| Rated Torque ((N.m/(r/min))) | — | 2800/1300 |
Turning
| Item | Unit | Value |
| Max Gradeability ((％)) | — | 42 |
| Braking Length ((m)) | — | ≤10 |
Boom Length
| Item | Unit | Value |
| Full-extend boom + jib | — | 135.3 |
