Parameters
| Item | Unit | Value |
| Dimension — Overall Length | mm | 13120 |
| Dimension — Overall Width | mm | 2750 |
| Dimension — Overall Height | mm | 4000 |
| Dimension — Wheel Base | mm | 1600+2450+1650 |
| Dimension — Wheel Tread | mm | 2340 |
| Weight — Travelling Weight | kg | 48000 |
| Weight — Axle Load | kg | 12000*4 |
| Travelling — Max.Travelling Speed | km/h | 80 |
| Travelling — Min.Stable Travelling Speed | km/h | 2.8 |
| Turning — Min Diameter of Turning Circle | m | 18 |
| Turning — Min Diameter of Turning Circle of Boom Head | m | 22 |
| Turning — Minimum Ground Clearance | mm | 350 |
| Turning — Approach Angle | ° | 17 |
| Turning — Departure Angle | ° | 16 |
| Turning — Fuel Consumption Per Hundred Kilometers | L | 60 |
| Main Performance Parameters — Max.Rated Lifting Capacity | t | 100 |
| Main Performance Parameters — Min.Rated Range | m | 3 |
| Main Performance Parameters — Max. Lifting Moment of Basic Boom | kN·m | 3000 |
| Main Performance Parameters — Turning Radius of Platform Tail | mm | 4510 |
| Outriggers — Lengthways | m | 8.76 |
| Outriggers — Transverse | m | 7 |
| Max. Lifting Height — Basic Boom | m | 11.7 |
| Max. Lifting Height — Full-extend boom | m | 60 |
| Max. Lifting Height — Full-extend boom + jib | m | 88.2 |
| Boom Length — Basic Boom | m | 11.7 |
| Boom Length — Full-extend boom | m | 60 |
| Working Speed — Max Rotating Speed | r/min | 1.7 |
| Lifting Speed — Main Hoisting Mechanism | m/min | 125 |
| Lifting Speed — Auxiliary Hoisting Mechanism | m/min | 110 |
| Boom Extend-retract Time — Full-extend | s | 550 |
| Luffing Time — Full Extension Time | s | 50 |
| Outrigger--horizontal — Open Simultaneously--horizontal | s | 40 |
| Outrigger--horizontal — Close Simultaneously--horizontal | s | 30 |
| Outrigger--Vertical — Open Simultaneously | s | 50 |
| Outrigger--Vertical — Close Simultaneously | s | 40 |
Kinetic Parameter
| Item | Unit | Value |
| Engine Model(Upper) | — | OM934LA |
| Rated Power ((kw/(r/min))) | — | 347/1700 |
| Rated Torque ((N.m/(r/min))) | — | 2200/1300 |
| Engine Model(Chassis) | — | OM471LA |
| Rated Power ((kw/(r/min))) | — | 129/2200 |
| Rated Torque ((N.m/(r/min))) | — | 750/1200-1600 |
Turning
| Item | Unit | Value |
| Max Gradeability ((％)) | — | 60 |
| Braking Length ((m)) | — | ≤10 |
Boom Length
| Item | Unit | Value |
| Full-extend boom + jib | — | 88.2 |
