All terrain truck crane

QAY500

QAY500 all terrain crane is equipped with new spacious luxury cab, combined center console, digital indicator, Grammer air suspension seat, electrical control rear mirror, etc. The product adopts 8-axle chassis, 6-axle steering, and 4-axle drive, featuring sufficient power. 7-seg

Parameters

Item Unit Value
Dimension (Unit) QAY500
Overall length mm 22140
Overall height mm 4000
Weight — Overall weight in transport kg 96000
Travel — Max. travel speed km/h 80
Travel — Min. turning diameter m 30
Travel — Approach angle ° 13.3
Travel — Departure angle ° 19.2
Travel — Max. grade ability % 35
Main performance — Max. rated total lifting capacity t 500
Main performance — Max. lifting torque kN.m 15190
Main performance — Longitudinal outrigger span m 9.6
Main performance — Lateral outrigger span m 10.123

Power

Item Unit Value
Engine model TAD750VE

OM502LA.E3A/1

Item Unit Value
Engine rated power (kW/(r/min)) 200/2300
