Wheel loader
ZL50GV
DescriptionSpecificationUnitRated operating load5000kgBucket capacity2.5 ~ 5.0m³Machine weight17300±
Parameters
| Item | Unit | Value |
|---|---|---|
| Rated operating load | kg | 5000 |
| Bucket capacity | m³ | 2.5 ~ 5.0 |
| Machine weight | kg | 17300±300 |
| Dump clearance at maximum lift | mm | 3100-3780 |
| Reach at maximum lift | mm | 1100-1220 |
| Wheel base | mm | 3300 |
| Tread | mm | 2250 |
| Max.breakout force | kN | 175±5 |
| Max.horse power | kN | 160±5 |
| Hydraulic cycle time-raise | s | <6 |
| Total hydraulic cycle time | s | <10.5 |
| Min. turning radius over tyres | mm | 5925±50 |
| Articulation angle | ° | 38 |
| Gradeability | ° | 30 |
| Tyre size | — | 23.5-25-16PR |
| Overall machine dimension Lx WxH | mm | 8225x3016x3515 |
| Model | — | WP10G220E343 |
| Rated Power/Speed | kW/rpm | 162/2000 |
