Mobile shotcrete pump
HPS20K
HPS20K — Mobile shotcrete pump. Professional construction equipment by CANMAX.
Parameters
| Item | Unit | Value |
|---|---|---|
| Whole machine weight | kg | 11800 |
| Dimension | mm | 8300×2040×2600 |
| Chassis | — | With chassis |
| Engine emission | — | Euro III |
| Engine rated power | kW/rpm | 62.5/2300 |
| Approach/departure angle — Max gradeability | % | 35 |
| Approach/departure angle — Max speed | km/h | 20 |
| Mini ground clearance — Turning radius | m | 3.5/6 |
| Sparying system — Max sparying height | m | 12 |
| Sparying system — Max sparying width | m | 20 |
| Sparying system — Max sparying distance | m | 10.8 |
| Sparying system — Mini sparying height in tunnel | m | 2.8 |
| Sparying system — Max working depth | m | 4.5 |
| Sparying system — Spray nozzle rotation angle | ° | 360 |
| Sparying system — Spray nozzle swing angle | ° | 240 |
| Sparying system — Spray nozzle swipe X angle | ° | 8×360 |
| Pumping system — Max pumping capacity | m³/h | 20 |
| Pumping system — Max pumping pressure | MPa | 7.5 |
| Pumping system — Concrete cylinder diameter/line | mm | 180/670 |
| Pumping system — Hopper capacity | L | 500 |
| Pumping system — maxi permitted diameter of aggregate (Pumping /Sparying ) | mm | 22/16 |
| Accelerator system — Max conveying pressure of accelerator | MPa | 0.8 |
| Accelerator system — Accelerator measurement/ convey capacity | l/h | 60～600 |
| Air compressor — Air supply volume | m³/min | 8.4 |
| Air compressor — Wind pressure | MPa | 0.8 |
Pumping system
| Item | Unit | Value |
|---|---|---|
| Distribution type | — | petticoat valve |
